Details

The Lectric XP4 marks the next step in the evolution of the XP series, combining improved performance, comfort, and portability. Designed for riders who want an eBike that’s both practical and fun, it easily folds down for travel or storage without sacrificing power or stability. This model features an upgraded in-house torque sensor that delivers smoother, more natural power assistance, along with a redesigned frame and fresh color options. A bright full-color TFT display keeps all your ride data visible, while the new 602 hydraulic brakes ensure dependable stopping power. Riders can choose between motor and battery options, including a 750W motor for stronger acceleration and a 17.5Ah long-range battery capable of reaching up to 85 miles per charge. With these enhancements, the XP4 offers a refined and reliable riding experience—ideal for commuting, exploring, or everyday use.

Specs

Drive System	Stealth M24 500W rear hub motor (1092W peak) delivering 55 Nm torque. Five riding modes (Eco, Tour, Sport, Sport+, Turbo) and left-hand thumb throttle for Class 1, 2, or 3 performance.
Display	Custom color TFT LCD display with detachable mount and USB-C port. Provides trip, battery, and power data. IP-X5 rated for water resistance with intuitive drop-down menus.
Battery Type/Weight	Integrated & removable 48V, 10.4Ah (500Wh) lithium-ion battery certified to UL 2271; powers up to 50 miles per charge. Battery weight: 7 lbs.
Charger Type	Standard 2A charger included (4–6 hour charge time); optional 5A fast charger available.
Recharge Time	˜ 4–6 hours with standard charger / ˜ 2 hours with fast charger.
Max. Assisted Speed	Up to 28 mph (Class 3) depending on riding mode and throttle use.
Range	Up to 50 miles per charge (terrain and assist level dependent).
Frame	Fully redesigned 6000-series aluminum folding frame; lightweight and sturdy with integrated rear rack (150 lb capacity) and multiple mounting points. Certified to UL 2849 and tested to ISO 4210 standards.
Fork	Adjustable front suspension fork with lockout for smooth and customizable ride.
Headset	Integrated sealed bearing headset for precise steering.
Axles	Front thru-axle system for wheel alignment and handling stability.
Rims/Wheels	Durable alloy rims engineered for 20” x 3” tires.
Hubs	Sealed bearing hubs for smooth, low-maintenance operation.
Spokes	Heavy-duty stainless-steel spokes for durability.
Tires	20” x 3” puncture-resistant tires with custom tread for low rolling resistance. Pre-installed with Slime sealant; reflective sidewalls.
Crankset	Forged aluminum cranks with 56-tooth custom chainring optimized for 20” wheels.
Chainrings	Single 56T chainring.
Bottom Bracket	Sealed cartridge bearing bottom bracket.
Chain	KMC Z8 steel chain with inner-plate chamfering for smooth, secure shifting.
Rear Derailleur	Shimano Altus 8-speed.
Cassette/Rear Cogs	11–32 tooth, 8-speed freewheel.
Shifters	Below-the-bar trigger shifter for precise gear changes.
Handlebars	Adjustable zero-degree stem with telescoping height adjustment for upright comfort.
Tape/Grips	Full-length ergonomic lock-on grips with internal sleeve for stability.
Stem	Zero-degree adjustable telescoping stem for custom fit.
Brake Levers	Ergonomic aluminum brake levers paired with hydraulic system.
Brakes	602 Hydraulic disc brakes with 180 mm rotors (2.3 mm thick) for reliable stopping in any condition.
Pedals	Custom 6000 Series Aluminum quick-release pedals with splined inserts for tool-free removal and improved traction.
Saddle	Custom-designed sport-comfort saddle.
Seatpost	Telescoping adjustable seatpost with quick-release collar.
